MecWash Maxi1200 Wash System

MecWash Maxi1200 Wash System

Maxi Front Load/Unload System

DOM: 2023

Wash chamber measures 24”W x 24”H x 48"

180° Indexing and Central Dividing Shelf

Variable Speed Basket Contra Rotation, Oscillation, Stationary Options

Rotational Re-Circulating Heated Spray/Flood Wash

Wash Mesh Strainer Basket (500μm Mesh)

Wash In-Line Cartridge Filter (rated 30μm)

Re-Circulating Heated Spray/Flood Rinse Tank

Rotational Vacuum Dry

Roller Conveyor 48” wide x 10’L including sliding pallets, drip tray, and guide

rails

The heated wash solution is sprayed over the rotating workload at a rate of 185

gallons per minute. The closing and opening of the wash return valve allows the

wash chamber to fill and empty quickly to achieve full penetration of complex or

densely packed components. At the end of the immersion stage, a spray

washensures all residual contamination is flushed away. This is followed by

immersion and spray rinse stages to remove the wash solution and further

contamination from the parts, to leave a quality finish.
