Dage XD7500VR 950 X-ray Inspection System

Dage XD7500VR 950 X-ray Inspection System

DOM: 2010

Standalone

Closed Tube

160kV

70 degree Oblique view

1,500 X Geometric Magnification (7,000 X system magnification)

Easy Collision-Free, High Magnification Inspection – even at oblique angle views

Maximum Board Size / Inspection Area – 20” x 17.5” (508 x 444 mm) with no oblique views

Maximum Inspection Area – 18” x 16” (458 x 407 mm) with oblique views

20” Digital Colour Flat Panel, Wide-Screen, LCD Operator Display

Tube:

High Resolution

950nm (0.95µm) feature recognition

Power – up to 3W

High Magnification – 1500X geometric mag.

Fully Functional
